全自動涼茬機是一種釀酒設備，具有速度快、效率高的特點?？勺詣蛹铀?、彎管、卸料、攪拌均勻，冷卻效果理想。每臺涼茬機都由折彎裝置組成，而折彎裝置是涼茬機中比較重要的設備之一。折彎裝置位于涼茬機底部，對出料口漏出的物料形成收集作用，從而節省物料，避免浪費。
Automatic stubble cooler is a kind of brewing equipment, which has the characteristics of fast speed and high efficiency. It can automatically add water, bend pipes, unload materials and mix evenly, with ideal cooling effect. Each stubble cooler consists of a bending device, which is one of the more important equipment in the stubble cooler. The bending device is located at the bottom of the stubble cooler to collect the materials leaked from the discharge port, so as to save materials and avoid waste.
傳統釀造過程中，出鍋后人工將糯米粒撒在指定位置，根據實際情況通過人工調節不斷調整醪糟的粗細，并通過風扇冷卻地下。需要不斷的人工調整，大大增加了工人的工作量。同時，由于醪糟的粗細不一致，醪糟的冷卻往往會導致冷卻不均勻，影響酒曲的效果，進而影響發酵后的酒量。
In the traditional brewing process, the glutinous rice grains are manually scattered at the designated position after coming out of the pot. According to the actual situation, the thickness of the ferment is continuously adjusted through manual adjustment, and the underground is cooled by a fan. Continuous manual adjustment is required, which greatly increases the workload of workers. At the same time, due to the inconsistent thickness of the ferment, the cooling of the ferment will often lead to uneven cooling, which will affect the effect of koji, and then affect the volume of wine after fermentation.
全自動涼茬機從根本上了這個問題。通過調節料斗擋板的高度，調節酒糟的移動粗細，達到均勻的目的。運行過程中，鏈板輸送帶底端由離心風機連續冷卻，根據風冷條件下均勻的工藝厚度，以及料斗底端與鏈板輸送機之間的間隙，調節風機的流量和風壓，使物料在鏈板輸送帶上均勻冷卻皮帶設計為可調節的。要求定制。
The automatic stubble cooling machine has fundamentally solved this problem. By adjusting the height of the hopper baffle, the moving thickness of the distiller's grains is adjusted to achieve the purpose of uniformity. During operation, the bottom end of the chain plate conveyor belt is continuously cooled by a centrifugal fan. According to the uniform process thickness under air cooling conditions and the gap between the bottom end of the hopper and the chain plate conveyor, the flow and air pressure of the fan are adjusted so that the materials can be uniformly cooled on the chain plate conveyor belt. The design of the belt is adjustable. Require customization.
采用自動涼茬機，冷卻秸稈網帶漏掉的秸稈直接落入本機設計的不銹鋼箱內。清洗后完全在水池中使用，清洗方便，杜絕浪費和環境污染。安裝前，車間地面不需要任何準備工作。它也可以根據需要在移動中使用。
The automatic stubble cooler is used to cool the straws. The straws leaked from the straws mesh belt fall directly into the stainless steel box designed by this machine. After cleaning, it can be completely used in the water tank, which is convenient for cleaning and eliminates waste and environmental pollution. Before installation, the workshop floor does not need any preparation. It can also be used on the move as needed.
與原有的涼茬機相比，全自動涼茬機具有更加明顯的優勢。自動吹茬機是在原有吹茬機的基礎上發展起來的。原來的發茬機冷卻發茬需要40-50分鐘。升級后全自動涼茬機僅需20分鐘左右，大大縮短了時間，提高了效率，縮短了工作時間。
Compared with the original stubble cooler, the full-automatic stubble cooler has more obvious advantages. Automatic stubble blowing machine is developed on the basis of the original stubble blowing machine. The original stubble machine needs 40-50 minutes to cool stubble. The upgraded automatic stubble cooler only takes about 20 minutes, which greatly shortens the time, improves the efficiency and shortens the working time.
在涼茬機的秸稈料斗出料口的正下方、在涼茬機底部的傳動鏈上方設有掛接籃。掛鉤籃的兩端分別固定在干茬機支架的橫梁上；掛鉤籃為一端抬起的折疊護板；折疊護板的凸起端設有調節螺栓，用于調節彎籃在橫梁上的折疊高度集合結構。
A hanging basket is arranged directly below the straw hopper discharge port of the stubble cooler and above the transmission chain at the bottom of the stubble cooler. Both ends of the hook basket are respectively fixed on the cross beam of the stubble dryer support; The hook basket is a folding guard board raised at one end; The convex end of the folding guard plate is provided with an adjusting bolt, which is used to adjust the folding height collection structure of the bending basket on the beam.
The above is the relevant content of the question to be shared with you today. I hope it will help you. If you want to know more, you can contact us by phone or follow our website http://www.xdyouyi.com 。
